Boston Gear Cast Iron Worm Gear Reducer Flange Input – Solid Shaft Output F721-30-B5-G

Frame: 56C, Manufacturer: Boston Gear, Output RPM: 350, Ratio: 30:1, Input HP: 1.00,

SKU F721-30-B5-G Category Flange Input-Solid Shaft Output Tags Boston Gear, Cast Iron, F721-30-B5-G, Flange Input - Solid Shaft Output, Worm Gear Reducer

Original price was: $1,012.00.Current price is: $935.46.

*Prices may change due to the current economic environment. We apologize for any inconvenience this may cause.

Orders usually ship within 1-2 business days.

Description

Description

5:1 – 60:1 ratios
Center distances ranging from 1.33 to 3.25 inches
One piece # Fc20 all cast iron housing
Embedded double-lip oil seals
S45C carbon steel shafts
Albc3 aluminum – bronze gear
Interior oil channel guide directly and constantly lubes bearings
Tapered roller bearing on output and input shafts
All angle – radiused mounting holes
Air dry special black paint
Shaft sleeve protects all shafts
Compact design – compact space capability
Units filled with Mobil # SHC634 synthetic oil
Interchangeability with major brands
1-year warranty
